Specifications

• Dry Weight - 900kg

• Total Length (Spare wheel incl)  4050mm

• Total Height to roof top  1970mm

• Total Height to top of Bush Wing (depending on tyre size)  ±2050mm

• Total Width  1850mm

• Ground Clearance (axle)  350mm

• Departure angle  44°

• Solid beam axle with leaf springs and shock absorbers  2500kg

• Double bed  1

• Small single bed (converts to table with two seats) 1

• Sleeps  2 Adults + 1 Infant

• Stainless Steel Body and Chassis

• Aluminium interior and doors

• Micro Dotted (also known as Data Dot) as per law specs.

• 5 Year structural warranty on chassis and main body

• 1 Year Guarantee (ex factory) on material and workmanship, other items as per manufacturer's guarantees

Standard Features

Optional Extra's

• Bush Wing awning 90° x 270° 1 x

• Sides for Bush Wing (2x doors)  5 x

• Draft skirt 1 x

• Mosquito net at door 1 x

• 15" Wheels, 6 stud, steel epoxy rims 3 x

• Kitchen with stainless steel working table 1 x

• Stabilizers/Jacks/High lift jacks 2 x

• Wheel spanner, lockable spare wheel 1 x

• Double cupboards for clothes with canvassing & zips 4 x

• Mattresses 1 x D + 1 x S

• Front bed with tent 1 x

• Inside floor carpet 1 x

• Heavy duty jockey wheel 1 x

• Jockey wheel out of the way bracket 1 x

• Aluminium checkered noseboxes 2 x

• Jerry can holder between noseboxes 1 x

• Jerry cans 2 x

• Aluminium woodracks on top of noseboxes 2 x

• Deep cycle batteries with cover boxes 2 x

• Outside kitchen LED light  1 x

• LED Lights (3x kitchen, 1each: roof, bed tents, entrance door,  geyser door) 8 x

• Hella points 12V output 3 x

• Anderson Fridge points 12V 50A  1 x

• 220V Inlet caravan plug  1 x

• 220V plug (3 point) outside at kitchen 3 x

• 220V plug (2 point) inside (built in breaker) 1 x

• 220V plug (3 point) inside (built in breaker) 1 x

• Intelligent Charging system, monitor and Bush Lapa power panel with USB plugs 1 x

• Charging system from vehicle (Anderson plug on A-frame) 1 x

• 220V Caravan extension lead for mains 10m 1 x

• Mudflaps 2 x

• Mudflap stone protectors for chassis 1 x

• Fire extinguisher  1 x

• Double wash basin on rear with aluminium frame (removable) 1 x

• Heavy duty aluminium kitchen drawer system  1 x

• Aluminium storage box next to fridge (to fit fridge specifications) 1 x

• 2 Plate gas cast iron burner fixed in stainless steel stand 1 x

• Direct gas connection to gas burner with regulator 1 x

• Gasbottle bracket in nosebox 1 x

• 105 Litre stainless steel water tank under chassis with automatic pump, filler cap, tap and drain plug 1 x

• Water meter 1 x

• 6 Litre/min Geyser with direct connection to rear tap 1 x

• Hot and cold water taps on rear for wash basins 1 x each

• Cutlery canvas holder  1 x

• Crockery set in foam holder in kitchen (for six) 1 x

• Spare wheel cover 1 x

• Transport included to Bush Lapa certified dealers (7 working days extra from factory completion date) 1 x

• Solar Panel 140W with MPPT 75/15A and aluminium roof rack

• 100W External solar panel with regulator, 10m lead & PVC bag

• National Luna 90L incl baskets (220V/12V)

• Snomaster 81.5L incl baskets (220V/12V)

• Bearing kit

• Mag Wheels 16'', 17'' or 18''

• Other axle than standard

• Shower Wing

• Gasbottle bracket

• Gasbottles (filled)

• 1200mm x 600mm Loose standing aluminium table with fold in legs and PVC bag

• Table strap only

• PVC Stoneprotector

• Bush Wing divider (@ kitchen)

• Upgrade to reflective flysheet - front bed

• Upgrade to reflective flysheet - side bed

• Microwave bracket (custom made)

• Windshield for gasstove (loose standing)

• Windshield/cover for gas stove - wind protector (fitted)

• Black stonechip nosebox

• Bush Lapa Bottle opener

• Eggbox mattress upgrade

• Memory foam mattress upgrade

• Gel memory foam mattress upgrade

• Anti-theft coupler lock

• Axe with bracket

• Spade with bracket

• Alko levellers in front under chassis (set of 2) incl spanner

• Top travel blanket

• Lower travel blanket

• Caravan Cover (Green/White)

• Engraved glass crockery set with foam holder

SELECT YOUR COLOUR & CANVAS COMBINATION

• Bush Lapa Khaki caravan with Bush Lapa Khaki canvas

• Bush Lapa Green caravan with Bush Lapa Khaki canvas

• Bush Lapa White caravan with Bush Lapa Grey canvas

• Bush Lapa Grey caravan with Bush Lapa Grey canvas
